FAG B7024-E-T-P4S ball bearings Dimension:120x180x28mm,in stock

Ask Lasest Price
Brand Name :	FAG
Model Number :	B7024-E-T-P4S
Certification :	ORIGINAL
Price :	NEGOTIATION
Delivery Time :	2 days
Payment Terms :	T/T
Supply Ability :	1000PCS/MONTH

Add to Cart

Product Details
Company Profile

FAG B7024-E-T-P4S ball bearings Dimension:120x180x28mm,in stock

FAG B spindle bearingsare with large balls, high speed and 25 degree contact angle, it has high load carrying capacity and high rigidity. Due to its very narrow tolerance, these super ball bearings are particularly suitable for applications involving the highest requirements for guidance accuracy, such as bearing arrangements for main spindles in machine tools.

The technical datasheet forFAG super precision ball bearing B7024-E-T-P4S,

Type: High speed angular contact ball bearing

Dimension: 120mm x 180mm x 28mm

Basic load rating: 106Kn – 110Kn

Limiting speed: 6700 r/min – 10 000 r/min

Weight: 2.1KGS/PC

Origin: made in Germany

There are many more FAG Super precision angular contact ball bearings,

FAG bearings：	d	D	B
	mm	mm	mm
B7000-E-T-P4S	10	26	8
B7001-E-T-P4S	12	28	8
B7002-E-T-P4S	15	32	9
B7003-E-T-P4S	17	35	10
B7004-E-T-P4S	20	42	12
B7005-E-T-P4S	25	47	12
B7006-E-T-P4S	30	55	13
B7007-E-T-P4S	35	62	14
B7008-E-T-P4S	40	68	15
B7009-E-T-P4S	45	75	16
B7010-E-T-P4S	50	80	16
B7011-E-T-P4S	55	90	18
B7012-E-T-P4S	60	95	18
B7013-E-T-P4S	65	100	18
B7014-E-T-P4S	70	110	20
B7015-E-T-P4S	75	115	20
B7016-E-T-P4S	80	125	22
B7017-E-T-P4S	85	130	22
B7018-E-T-P4S	90	140	24
B7019-E-T-P4S	95	145	24
B7020-E-T-P4S	100	150	24
B7021-E-T-P4S	105	160	26
B7022-E-T-P4S	110	170	28
B7024-E-T-P4S	120	180	28
B7026-E-T-P4S	130	200	33
B7028-E-T-P4S	140	210	33
B7030-E-T-P4S	150	225	35
B7032-E-T-P4S	160	240	38
B7034-E-T-P4S	170	260	42
B7036-E-T-P4S	180	280	46
B7038-E-T-P4S	190	290	46
B7040-E-T-P4S	200	310	51
B7044-E-T-P4S	220	340	56
B7048-E-T-P4S	240	360	56

FAGSuper precision bearings are made from high quality materials, through specific heat treatment, a long material fatigue life and wear resistance is achieved with the result that the bearings can be run permanently in many cases.

The delivery time: in stock, within one day after getting the order

Package:standard carton or standard wooden case

Shipping term:TNT,FEDEX,DHL Express or your required
